TS4162625- Trailer Axle Nut
TS4162625- Trailer Axle Nut
The first true single piece nut design delivers accurate adjustments within .001" which will extend the wheel bearing and seal service life. Adjustments are made in half the time others require. The design is superior to the three piece style jamming nut system and two piece models that require locking keepers. This nut requires only one installation tool, a six point socket & torque wrench. Available for trailer, drive and steer axles with the standard "D" flat or slotted spindles
SPECIFICATIONS
Axle Type: Trailer Axle
Thread: 2-5/8"-16
W.A.F: 3.250"-6
Thickness: 1.060"
Applications
Dana Spicer Trailer Axles: D-20, D-21, D22, DD-21, DD-22, K-21, K-22, K-25, K-30
Eaton Trailer Axles: C, C2, CD, CD2, CE, ESA-225J, EST, EST-225J, EST-230J, ETA 230C, ETA 225D, ETA 225J, H23L, H25R, HCE, HJ, HJE, J, JE, JH, LA-15, T-18 C, 20L-77, 22L, 22R, 23L, 23R, 25R
Hendrickson Trailer Axles: HN
Ingersoll Trailer Axles: A22T
Meritor Trailer Axles: RL Series, RQ Series, TK Series, TKL Series, TKLD Series, TL Series, TLD Series, TN Series, TND Series, TQ Series, TQC Series, TQD Series
Standard Forge Trailer Axles: A25, A26, 17,000lb-22,500lb Axles
Meritor Drive Axles: F Series, H Series
CROSS REFERENCE: 447-4743, AX12-3480-2625, MF111051, 4162625, 209.T2625
