5546000- Buyers 8-19 Foot Tarp Kit 600W/90:1 Gear Motor - 4 Springs With Wind Deflector
5546000- Buyers 8-19 Foot Tarp Kit 600W/90:1 Gear Motor - 4 Springs With Wind Deflector
Reliably covers and protects your payload.
Slim underbody mount keeps the pivoting unit protected and out of the way.
Choose from high speed, high torque or regular gear motors with 1 or 3 year warranties.
Fingertip electric controls for ease of operation.
Sturdy weather and corrosion-resistant aluminum components for reliable performance, time after time.
Fits dump bodies from 8 ft to 19 ft long.
Aluminum Underbody-Spring Mount Tarp System for 8 to 19 Foot Dump Bodies keeps your payload in the truck and out of the weather. With strong, reliable technology and fingertip controls, the Underbody-Spring Mount Tarp System has got you covered. The telescoping tarp arms utilize a single underbody-mounted spring instead of two side-mounted springs to maintain tension. The design is simple, strong, and preserves a slim profile where the pivots attach to the dump body.
The tarp system works time after time, thanks to its sturdy aluminum arms that telescope to fit dump bodies ranging from 8 ft to 19 ft. An optional aluminum wind deflector protects the tarp from wind and weather bombardment. At the back, an optional extruded aluminum tension bow keeps the tarp from flapping in transit.
The system's gear motor features a bronze alloy gear for long life, protected by a weatherproof enclosure with a chrome cover. The system is available with the following motor options: High speed, 60:1 motor with a 1 or 3 year warranty
High torque, 90:1 motor with 3 year warranty
Regular speed, 90:1 motor with a 1 or 3 year warranty
Tarps are sold separately.
Product Common Use: Dump Applications, Manual Tarp Systems
SPECIFICATIONS
Arm Material: Aluminum
Arm Type: Telescoping
Motor Horsepower: 0.8 HP
Motor Output Shaft Length: 3.13"
Number Of Springs Per Arm: 1
System Style: Electric Underbody
Wind Deflector Material: Aluminum
Dump Length Minimum: 8'
Motor Output Shaft Diameter: 0.75"
Motor Gear Ratio: 90:1
Motor Wattage: 600W
Wind Deflector Included (Y/N): YES
Motor Amperage: 50 A
Motor Voltage: 12 VDC
Motor Mounting Pattern: 5 Hole
Wire Gauge: 8 ga
Wire Length: 60'
Circuit Breaker Amperage: 60 A
Solenoid Amperage: 150 A
Number Of Bumpers Included: 6
Dump Length Maximum: 19'
Wind Deflector Width: 98"
Tarp Included (Y/N) NO
Motor Warranty Length: 1 Year
