DESCRIPTION
The Remote Mount Small Dump Pump - Air Controlled from Buyers Products is a compact source of hydraulic power ideal for smaller dump applications.
Choose from two models for the GPM flow that meets your needs.
The pump includes a 4 bolt SAE mounting flange and 7/8 in. by 13 spline shaft, and third line sleeve.

Air controls sold separately.

SPECIFICATIONS
Displacement: 2 in 3/r
Flow: 11 GPM
Gear Width: 1.500"
Imput Mount Type: Frame Mount
Material: Cast Iron
Maximum Rotations Per Minute (RPM): 2000 RPM
Mount Type: Frame Mount
Shaft Size: 1
Shaft Type: Round/Keyed
Ports(Rear/Side): Rear
Inlet Port Size: 1-1/4 NPT
Maximum Pressure: 2500 PSI
Direct or Remote Mount: Remote Mount
Outlet Port Size: 3/4 NPT
Rotation: Clockwise or Counterclockwisel
Gear Size: 1.5"
Flow At 600 RPM: 7.00 GPM
Flow At 1000 RPM: 11.7 GPM
Flow At 1800 RPM: 21 GPM
Flow At 900 RPM: 10.44 GPM
Flow At 1200 RPM: 14.04 GPM
Flow At 1500 RPM: 16.76 GPM
Flow At 2100 RPM: 54.57 RPM
Rear Port Size: 3/4 NPT
Suction Port Size 1 -1/4 NPT
