AB1DK23M-P117-Air Spring Rolling Lobe
AB1DK23M-P117-Air Spring Rolling Lobe
CROSS REFERENCE: 65282002, 69153002
Specifications:
| Applications | Hendrickson |
| Type | Rolling Lobe |
| Air Spring Brand | Automann Phoenix |
| Automann Bellows # | 1DK23M |
| Contitech Bellows# | 9 10-18.5 |
| Load (Lbs) @80 PSI | 5900 |
| Load (Lbs) @100 PSI | 7500 |
| Natural Freq. (CPM) | 57 |
| Design Height (In) | 12.50 |
| Bottom Plate Type | Plastic |
| Top Plate Hole/Stud Qty | 2 |
| Top Plate Dia. (A) | 9.00 |
| Top Plate C to C Dia. (B) | 5.87 |
| Bottom Plate Hole/Stud Qty | 2 |
| Bottom Plate Dia. (C) | 10.00 |
| Bottom Plate C to C Dia. (D) | 6.75" |
| Bottom Part # | BS08660 |
| Bumper | No |
| Min. Height | 8.00 |
| Max. Height | 23.10 |
| Max. Dia. | 12.60 |
